Input your building structure to automatically draft single-line block diagrams, route cables around obstacles, perform voltage-drop checks, and print clean electrician handout checklists.
Every capability is designed to save drafting time and enforce standard installation guidelines.
Input your levels and apartment configurations. The layout engine instantly generates orthogonal single-line block diagrams without manual drawing.
Cables route around equipment symbols and annotation boxes rather than cutting straight through them, creating professional CAD-grade blueprints.
Set hardware thresholds (e.g. 8 or 24 ports). The engine monitors connection limits and auto-routes subsequent cables to available secondary switches.
Reposition room boundaries inside apartments. Drag rooms on the grid, swap widths/heights, flip layout mirrors, and copy floor layouts to save time.
Check DC voltage drops based on cable gauges. Calculate Sealed Lead Acid battery standby capacities automatically under AS/NZS 2201 (Security) and AS 1670.1 (Fire) standards.
Print an installation guide broken down by floor, apartment and room. In the browser, each device can be ticked from pending to installed to tested, and the project's progress counters follow along.
Change the building structure below to watch the schematic redraw and recalculate costs.
ComplyCAD runs active mathematical checks based on Australian standards directly inside your diagram canvas:
Enforces standby sizers (4h to 24h) for Sealed Lead Acid (SLA) batteries based on total quiescent device currents.
Calculates required dual-battery 24V series cabinets, incorporating a 25% aging degradation margin.
Checks Ohm's Law voltage drop along A* generated wire lengths, warning of low operating power.
Prices are in AUD per month. Starter and Professional both begin with a 14-day free trial — no charge until the trial ends, cancel any time from the billing portal.
For local electricians and small residential builders.
14-day free trial
For commercial low-voltage system integrators.
14-day free trial
For larger firms with requirements beyond the standard plans.
Priced per engagement
Items marked "on request" are not part of the product today. Tell us what you need and we will quote it.
A free account is included with sign-up: one active project, so you can try the wizard before subscribing.
